特服(TFKSM-B)快速门主要是由门框架系统，门帘系统，驱动电机，控制系统，安全系统组成。

　　框架材质为优质不锈钢制成，门帘为进口PVDF膜材和铝合金型材组成。驱动电机由刹车片，马达，减速机组成。控制系统是由PLC/变频器/编码器成套或自带

　　IPM模块的集成电路板， 安全系统由红外线电眼开关，安全气压传感器或光幕系统;升降速度：0.8m/s-1.5m/s，从底到顶一般在2秒钟左右(速度是电动卷闸门的20倍)，车辆、行人无需等待，不构成障碍，开门触发信号有多种方式：手动按钮、雷达感应、红外线光电感应、地磁感应、遥控等等。

　　广泛适用于食品、化学、纺织、冷冻、电子、印刷、装配、精密机械、物流、仓储等多种场所.

　　Tefu high speed door (TFKSM-B) consists of door frame, door curtain drive system, control system, security system. The door frame is made of high quality stainless steel.

　　Door curtain is made of imported high density fabric cloth and aluminum alloy ribs. Drive system is made up of brakes, motor and reducer. Control system is composed of PLC / Converter / Encoder comes with complete or IPM module's circuit boards. Electric eye safety system is composed of infrared photocell, safety edge and light curtain sensor. Running speed: 0.8-1.5m/s, generally it just take only 2seconds from bottom to tops (20 times of normal rolling shutter door), for vehicles and pedestrians, no needing waiting, never be a obstacle. There are several ways to open the door: manual button, radar sensor, and infrared photocell sensor, loop detector sensor, remote control and so on. Widely used in industries of food, chemical, textile, refrigeration, electronics, printing, assembly, precision machinery, logistics, warehousing and other places.

　　快速卷门(TFKSM-B)性能特点　　

　　箱罩与轨道采用优质不锈钢板制作。

　　表面经过拉丝处理，既美观且耐用。

　　适用于腐蚀环境较高的场所。

　    Door head cover and rails are made of high quality stainless steel plate. Surface is treated by polish, both beautiful and durable. Suitable for high corrosive environment of the place.　

　　门轨两侧配光电保护开关。门体运行时，如红外线光束被阻挡时门体自动返回。门体底部装有安全气囊，在门体下降过程中，遇到障碍自动返回。

　　Both bottom sides of the rails are installed photocell sensor.

　　While the door is running, the door will automatically rebound if infrared beam is blocked. The bottom of the door is equipped with safety edge, the door will rebound automatically if encounter obstacles while the door is falling.

　　门体四周装有优质密封材料，

　　可减少噪音，增加密封防尘效果。满足洁净需求。

　　　Around of the door is installed high quality sealing materials, which is good for reducing noise, increasing the effect of sealing and anti-rust. Meet the demand of clean environment.　

　　每一档门在出厂前都经过严格测试，确保无任何品质问题。

　　　Each door must be strictly tested before delivery, ensure without any quality problems.　

  　高速电机、微电脑变频+PLC控制，性能更稳定可靠。

　　适合高频率开关环境。

　　High-speed motor and\ micro inverter & PLC control make the performance more stable and reliable.

　　Suitable for high frequency switching environments.

特服门业本着精益求精的企业精神，向客户提供一流的产品，一流的服务,让客户真正感受到用我们的产品能“放心、定心、省心”。客户满意是我们永远追求的目标。咨询电话：510-81006920。
